11m Outdoor Square Galvanized Parking Lot Light Pole With Double Arms

one 40 HQ
MOQ
قابل مذاکره
قیمت
11m Outdoor Square Galvanized Parking Lot Light Pole With Double Arms
امکانات گالری توضیحات محصول درخواست نقل قول
امکانات
مشخصات
Height: 6m to 15m
Minium yield strength: 355mpa
Max ultimate tensile strength: 620mpa
Optical assembly of lighting fixture: IP65
Wind speed: 160km/h
Design of pole: Against earthquake of 8 grade
برجسته کردن:

street lighting poles,street lamp pole

,

street lamp pole
اطلاعات اولیه
Place of Origin: China
نام تجاری: Milky Way
گواهی: ISO, BV,
Model Number: 11m outdoor square galvanized Parking Lot Light Pole with double arms
پرداخت
Packaging Details: as customer request
Delivery Time: 20 days after confirm the order
Payment Terms: T/T
Supply Ability: 300 poles per day
توضیحات محصول

11m Outdoor Square Galvanized Parking Lot Light Pole With Double Arms





Specification



Material: high quality Q235 hot rolled steel
Mounting Height: 3-12m or according to the requirements of customers
Shape of pole: Round,conical,octagonal,square,mid hinged,polygonal shafts are made of steel sheet that folded into required shape and welded longitudinally by automatic welding machine
Brackets: Single or double brackets are in the shape and dimension as per customers requirement
Base plate: Base plate is square or round in shape with slotted holes for anchor bolt and dimension as per customers requirement
Ground mounted: The length buried underground as per customers requirement
Galvanizing: Hot dip galvanization with thickness of 80-100µm average
Powder coating: Pure polyester powder painting, color is optional



11m Outdoor Square Galvanized Parking Lot Light Pole With Double Arms 0



Product features:

1. Imported LED chip, UV and infrared, light-efficient, more stable.
2. LED packaging using high thermal conductivity of patented technologies and patented three-chamber cooling technology to effectively reduce the light resistance, the clip junction temperature can  be controlled at 60 degrees below, to ensure the lamp life of over fifty thousand hours or more chips.
3. The use of ultra-high thermal conductivity aluminum radiator, corrosion-resistant surface coating superconducting hot metal paint, to ensure faster heat generated LED light source distribution.
4. Use of patented technology and specialized secondary optical lens specially designed for LED specturm and high light transmission tempered glass lamp shade, to ensure that lighting a light rate of 85% or more.
5. Wide input voltage AC drive voltage constant current, ensure that the lighting for different countries and regions, high power factor, harmonic small. Constant current driver can adjust the brightness according to different time slots.
6. Lamp appearance by the professional aesthetic design, simples, elegant, fashion.
7. Applications: highway, main roads secondary roads, alip roads and so on.

11m Outdoor Square Galvanized Parking Lot Light Pole With Double Arms 1

Production Process


Material preparation-bending-welding-repair and grinding-reforming-flushing-fix bottom plate-welding bottom plate-opening door-welding door strip, electric strip, and locking-bending arm-hot dip galvanization-plastic powder painted-inspection-shipment.



11m Outdoor Square Galvanized Parking Lot Light Pole With Double Arms 2
