Galvanized Steel Power Transmission Poles 25ft-40ft 10kV-220kV

تصویر بزرگ : Galvanized Steel Power Transmission Poles 25ft-40ft 10kV-220kV

جزئیات محصول:

محل منبع:	چین
نام تجاری:	MilkyWay
گواهی:	ISO9001/BV/
شماره مدل:	قطب برق فولادی گیربکس

پرداخت:

مقدار حداقل تعداد سفارش:	1 قطعه
قیمت:	قابل مذاکره
جزئیات بسته بندی:	به عنوان درخواست مشتری
زمان تحویل:	20 روز کاری پس از دریافت پرداخت شما
شرایط پرداخت:	T/T ، L/C در دید
قابلیت ارائه:	300 عدد در روز

مخاطب

توضیحات محصول جزئیات

نام محصول:	تیر برق گالوانیزه	شکل:	هشت ضلعی یا گرد
ظرفیت قدرت:	10 کیلو ولت تا 220 کیلو ولت	مشترک لهستانی ها:	مفصل لغزش
زمان گارانتی:	15 سال	ضخامت:	1 میلی متر تا 36 میلی متر
برجسته کردن:	galvanized steel power transmission poles,25ft-40ft power transmission poles,10kV-220kV power transmission poles , 25ft-40ft power transmission poles , 10kV-220kV power transmission poles

Galvanized Steel Power Transmission Poles for Utility Lines

Available in 25ft, 30ft, 35ft, and 40ft lengths with competitive pricing

Product Specifications

Product Name	Galvanized Power Pole
Shape	Octagonal Or Round
Power Capacity	10kV to 220kV
Joint of Poles	Slip joint
Warranty time	15 years
Thickness	1 mm to 36mm

Steel Material Quality

All materials are sourced from reputable mills to ensure quality. Each shipment includes a mill certificate with stamp and signature for verification before unloading.

Before production, all materials undergo rigorous chemical and physical analysis to confirm they meet required strength and composition standards.

Galvanized Steel Power Transmission Poles 25ft-40ft 10kV-220kV 0

Detailed Specifications

Types Length	45ft	50ft	55ft	60ft	65ft	70ft
13.75m	15.25m	16.80m	18.30m	19.85m	21.35m
B (0°-2°)
Top diameter (mm)	200	200	200	200	200	200
Butt diameter (mm)	345	370	395	415	435	455
Thickness (mm)	6	6	6	6	6	6

Manufacturing Tolerances

Component Length: -25mm to 75mm
Straightness: 2mm/m
Twisting degree: 1° per 3 meters length
Ovalisation: Maximum is 3%
The average diameter: +/-0.5%
Slip length: +/-150mm

Galvanized Steel Power Transmission Poles 25ft-40ft 10kV-220kV 1

Welding Standards

Our welding processes have passed flaw testing. We use internal and external double welding for both strength and aesthetic quality.

Welding Standard: AWS (American Welding Society) D 1.1

Galvanized Steel Power Transmission Poles 25ft-40ft 10kV-220kV 2

Surface Treatment

Hot dip galvanized following ASTM A 123 standards. Custom color polyester powder or other client-required finishes available.

Company Introduction

Jiangsu Milky Way Steel Poles, established in 1991 and located in Wuxi, China near Shanghai Port, has over 24 years of experience manufacturing steel poles including transmission power poles, street light poles, and high mast poles.

Since 1991, we've exported to over 70 countries worldwide including the USA, Australia, Russia, Germany, Spain, Philippines, Malaysia, and throughout Africa.

We've supplied major projects globally, including street light poles for Dubai Tower and high mast poles for the Sochi Winter Olympic Games.
